Product Model
NVR-9908G-H1(P8) |
Video Output Interface
Equipped with 1 HDMI output (supports 4K resolution) and 1 VGA output (1920x1080 resolution), providing high-definition display. |
Power Supply
Supports AC100~220V wide voltage input (50Hz/60Hz), suitable for various power environments. |
Recording Frame Rate and Bitrate
Supports 8 channels of video recording, with resolutions from 8MP to 720P, and a total frame rate of up to 240fps. Each channel's recording frame rate and quality can be independently adjusted, with the main stream bitrate ranging from 512kb to 1Mb, and the sub-stream from 128kb to 1024kb. |
Audio Support
Provides 8 channels of audio input for IP cameras, plus 1 independent MIC input and 1 audio output. |
Screen Display Modes
Offers 1/4/6/8/9 split-screen options, and features automatic screen cycling and multi-segment digital zoom. |
Hard Drive Storage
Can accommodate 1 x 3.5-inch SATA hard drive, with single hard drive support from 1TB to 16TB (subject to brand and compatibility). |
Recording Schedule
Offers various recording methods, including continuous, scheduled, motion, alarm, and composite recording (continuous + motion, continuous + alarm, continuous + motion/alarm). |
Playback Function
Supports single or multi-screen playback during monitoring, and can simultaneously play back 8 channels. |
Network Protocols
Supports multiple network communication protocols, such as HTTP, TCP/IP, UDP, DHCP, DNS, PPPoE, DDNS, E-mail, etc. |
Video Input Capability
Supports video signal input from 8 IP network cameras. |
Recording Quality
Offers six quality settings: highest, higher, high, general, lower, low, to meet different storage needs. |
Device Dimensions
Dimensions are 300mm (W) x 50mm (H) x 250mm (D), a compact design. |
System Information Display (OSD)
The screen can display various information such as hard drive status, time, camera settings, recording settings, and function menus. |
Data Backup Methods
Supports data backup via USB or network, offering flexible backup options. |
Playback Search Modes
Provides file slice search, arbitrary date/time search, file time search, and event search to quickly locate desired video segments. |
Device Weight
Product net weight is approximately 1.0kg, gross weight with packaging is approximately 1.2kg (excluding hard drive). |
Motion Detection and Video Masking
Motion detection supports 22 x 15 area settings and offers 8 levels of sensitivity adjustment; video masking function allows setting 4 areas. |
Video Playback Speed
Supports forward/reverse playback, with speeds adjustable from x1 to x32, for quick review or slow analysis. |
