VT-4DH100DA

  • Item：AHD to HDMI, VGA, CVBS Converter
  • Spec.：One in, Three out/1080P
Features
  • Converts HD-TVI, AHD, HDCVI, NTSC/PAL, 960H to HDMI, VGA, and composite video.
  • Resolution up to 1080p@25/30Hz for input, HDMI & VGA up to 1080p.
  • Built-in loop out for an extra analog video input or a HD-TVI, AHD, HDCVI, CVBS output.
  • HDMI, VGA, CVBS output simultaneously.
  • Built-in PIP, display two input video.
    Inquiry
    Inquiry List
    Includes
    •   High-level transformer *1 (Pass the UL Certification )
    •   Manual *1
    Specifications
    ITEM NO.
    VT-4DH100DA
    Video Format
    HD-TVI / AHD / HDCVI / HDMI / VGA / CVBS
    Max. Input Video Resolution
    1080P@25/30Hz
    Max. HDMI Resolution
    1080P@60Hz
    Max. VGA Resolution
    1080P@60Hz
    Max. Composite Video Resolution
    480i, 576i(NTSC, PAL)
    Video Input
    1x75Ω BNC
    Video Output
    1xHDMI Type A, 1xD-SUB 15
    Video Loop-out
    1xBNC (75Ω 1Vpp)
    Switch
    1xDIP Switch, 2x Tact Switch
    Power Supply
    12V 500mA
    Power Consumption
    350mA, 4-5 Watts
    Operation
    0~55°C
    Storage
    -20~85°C
    Humidity
    Up to 95%
    Dimension
    88 x 130 x 30 mm
    Weigh
    275g
    Notice
    • Do not expose in moist environment, this product is not waterproof, make sure to install in proper location.
    • Please handle with care, this product contains highly precision components.
    ※Specifications and product designs are subject to change without notice.
