VT-KHP90PI

  • Item：4 Port Long Reach PoE Extender over
  • Spec.：90W/CAT5e 800M
Features
  • Extends PoE signal over a cost-effective Ethernet cable.
  • Signal extension up to 800M over CAT5e (or greater) cable.
  • Provides up to 90W power for remote PoE device.
  • Power source from either a PoE switch or an external power adapter.
  • Bandwidth up to 100Mbps.
    Inquiry
    Inquiry List
    Includes
    • VT-HP90PI x 1+VT-RP90PI x 1
    Specifications
    ITEM NO.
    VT-KHP90PI
    Compliance
    IEEE 802.3 10BASE-T Ethernet
    IEEE 802.3u 100BASE-TX Fast Ethernet
    IEEE 802.3 N-Way Auto-Negotiation
    IEEE 802.3x Full Duplex Operation and Flow Control
    IEEE 802.3af Power over Ethernet
    IEEE 802.3at Power over Ethernet Plus
    Network Bandwidth
    10/ 100Mbps
    Max. Transmission Distance
    10Mbps at 1000M, 100Mbps at 500M
    Input
    1 x BNC (75Ω), 1. x RJ45 (Yellow) / 1 x RJ45
    Output
    4 x RJ45 (Black) / 1 x RJ45
    Power Interface
    1 x (5.5 x 2.1mm) DC Jack / 1 x (5.5 x 2.1mm) DC Jack
    Power Supply
    24 ~ 56V Regulated / 48 ~ 56V Regulated
    Power Consumption
    6W / 1W
    Operation
    0 ~ 50℃
    Storage
    -20 ~ 85℃
    Humidity
    Up to 95%
    Dimensions
    67 x 135 x 27mm / 67 x 135 x 27mm
    Weight
    205g
    Notice
    • Do not expose in moist environment, this product is not waterproof, make sure to install location.
    • Please handle with care, this product contains highly precision components.
    ※Specifications and product designs are subject to change without notice.
