VT-PDH111-KL

  • Item：HD-TVI/AHD/HDCVI/CVBS Video & Power Balun with Pigtail
  • Spec.：HD-TVI/AHD/HDCVI/CVBS Video
Features
  • Resolution up to 4K (8MP).
  • Signal extension up to 300M over CAT5e (or greater) cable.
  • Built with DC plug for power transmission.
  • Male BNC to RJ45 connector with pigtail design.
  • Built-in ESD, EFT(impulse noise) and transient protection.
Inquiry
Inquiry List
lncludes
  •  VT-PDH111-KL
Specifications
ITEM NO.
VT-PDH111-KL
Max. Video Resolution
8MP (4K)
Max. Transmission Distance
HD-TVI 100M at 1080p
AHD 150M at 8MP
HDCVI 100M at 8MP
CVBS 300M (NTSC/ PAL)
Signal Bandwidth
50Hz to 60MHz ( -3dB )
Video Input/ Output
1 x BNC (1 Vp-p, 75 Ohm)
Link Interface
1 x RJ45 (100 Ohm)
Power Interface
1 x DC Plug (ø2.1 x 5.5mm) / 1 x DC Jack
ESD Protection
30kV(Air), 15kV (Contact), IEC 61000-4-2
EFT Protection
40A(5/50ns), IEC 61000-4-4
Lightning Protection
2A (8/20μs), IEC 61000-4-5
Response Time
<1 nS
Operation
0 to 55℃
Storage
-20 to 85℃
Humidity
Up to 95%
Dimension
52.6 x 25 x 20.7mm & 120mm pigtail cable
Weigh
45g
Notice
  • Do not expose in moist environment, this product is not waterproof, make sure to install location.
  • Please handle with care, this product contains highly precision components.
※Specifications and product designs are subject to change without notice.
