IP-C180W

  • Item：CUBE Camera
  • Spec.：2MP/IR 10M/WiFi
Features
  • "This product is for OEM projects in Taiwan and is an export model not sold in Taiwan."
  • (Pet Monitor): This product can be used to remotely monitor your pets at home via mobile phone or computer, and you can also hear audio.
  • 1/2.7” CMOS 2 Megapixel IR color camera.
  • Adopts H.265/H.264/MJPEG compression format and supports dual-stream design.
  • Built-in high-brightness LED infrared, with an effective illumination distance of 10 meters.
  • Supports IE, TTIC CMS central control software, and various TTIC DVRs for convenient management.
  • Supports local and network storage, playback, backup, and other functions.
  • Built-in IR-CUT dual filter for automatic switching; color to black and white in low light, or manual forced switching.
  • Supports POE, ONVIF, and 2D & 3D noise reduction functions.
  • Features SD card functionality (maximum support 128G).
  • Features wireless Wi-Fi functionality.
  • Features PIR functionality.
  • Built-in megapixel wide-angle lens 2.8mm.
  • Supports remote monitoring, playback, and backup of recorded data via smartphones/tablets.
  • Supports alarm I/O function.
  • Supports dual-system synchronous monitoring and recording.
  • Ultra-wide angle 110°.
Inquiry
Inquiry List
Includes
  • DC Power*1、Screws Group*1
Specifications
Product Model
IP-C180W
System
NTSC / PAL (selectable by region)
Minimum Illumination
0.03 Lux (F/1.2) 0 Lux IR/ON
Resolution
2MP (1920x1080) @ 30FPS
3 Stream Resolutions
1920x1080 / 1280x720 @30fps
1280x720 / 704x480 / 352x240 @30fps
704x480 / 480x240 / 352x240 @30fps
Image Settings
Saturation / Brightness / Contrast / Sharpness
Image Quality / Bitrate
VBR: 5 adjustable levels / CBR: arbitrary setting / 128Kbps~6Mbps
White Balance Control / Wide Dynamic Range
Auto Tracking White Balance (2500∘K～9500∘K) / Multi-level adjustable
Electronic Shutter
1～1/10,000 seconds
Motion Detection
3 selectable areas (8-level adjustable sensitivity and multi-segment schedule adjustable)
Video Masking
Features 4 video masking blocks
Alarm Input/Output
1/1
Network Protocols
TCP/IP, UDP, DHCP, DDNS, NTP, RTSP, FTP, SMTP, PPPoE
Audio Input/Output
Built-in 1 input / 1 output
Network 10/100 Interface
RJ45 connector / (Max. 10 simultaneous users)
Power
POE / DC12V; 1A / 4.5W (IR ON)
Weight
Net weight / Gross weight: 0.15Kg / 0.2Kg
Operating Temperature
-10℃～50℃
Dimensions
71(W) mm x 30(D) mm x 130(H) mm
Notice
  • Do not expose in moist environment, this product is not waterproof, make sure to install location.
  • Please be careful handling, this product contains the very high degree of precision parts inspiration.
※Specifications and product designs are subject to change without notice.
